Max Output (delivery pressure): 1,000KPa / 10 bar / 145psi
Max Inlet (cylinder pressure): 20Mpa / 20,000Kpa / 200 bar / 2900psi
CONNECTIONS
Outlet: "1/4 Flare" (JIC 37° Flare Fitting) with thread size / O.D. 7/16-20 (= approx 11.1mm)*
*Note: Australian Standards does not permit use of 5/8" UNF outlet on regulators exceeding 2,000 kpa output
Inlet: Type 50 (W24x2 14 TPI RH Female nut)
Port (inlet & outlet port hole in regulator body): 1/4" NPT (tapered)
OTHER SPECIFICATIONS
Operating (ambient) temperature range: -20°c - +60°c
