Amperage: 20 A – 500 A
Weldable Metals: Stainless Steel, Steel
Rated Carbon Diameter: 5/16 in (8 mm)
Current Type: DC
Max Open Circuit Voltage: 92 VDC
Portability: Lift Eye (Standard) | Trailer (Optional)
Cold Weather Starting Aids: Engine Block Heater, Glow Plugs
Engine Brand: Deutz
Engine Compliance: T4F
Engine Idle Speed: 1350 RPM
Engine Weld Speed: 1800 RPM
Fuel Tank Size: 95 Litres ( 25 Gallons )
Fuel Type: Diesel
Horsepower: 32hp
Weld Output: 20–500 A (CC/DC Stick/TIG), 14–50 V (CV/DC/MIG/FAW)
Rated Output: 400 A at 36 V 100% Duty Cycle, 450 A at 33 V 60% Duty Cycle, 500 A at 30 V 40% Duty Cycle
Generator Output: 20-500 Amp 12Kva
Auxiliary Power: 1 x 415V 32A 3-phase socket and 2 x 240V 15A 1-phase sockets (21,000W peak / 15,000W continuous 60Hz generator power
Single Phase Auxiliary Peak Power: 21000 W
Sound Rating: Idle: 66 dB, Weld: 71.6 dB
Applications: Fabrication, Mobile Fabrication & MRO, Process Pipe, Structural Welding
Net Width: 724mm
Net Height: 1,067 mm (1,258 mm including the exhaust)
Net Length: 1,654mm
Net Weight: 694kg ( without fuel )
Warranty: 3 Years Miller’s True Blue Warranty
Download Manual: https://www.millerwelds.com/files/owners-manuals/O281496S_MIL.pdf
