Amperage: 40 A – 600 A
Weldable Metals: Stainless Steel, Steel
Rated Carbon Diameter: 5/16 in (8 mm)
Current Type: DC
Max Open Circuit Voltage: 32 VDC
Portability: Lift Eye (Standard) | Trailer (Optional)
Cold Weather Starting Aids: Engine Block Heater, Glow Plugs
Engine Brand: Deutz TD2011L04W
Engine Compliance: T4F
Engine Idle Speed: 1350 RPM
Engine Weld Speed: 1500 RPM
Fuel Tank Size: 95 Litres ( 25 Gallons )
Fuel Type: Diesel
Horsepower: 65.7hp
Weld Output: 40–600 A (CC/DC Stick/TIG), 15–50 V (CV/DC/MIG/FAW)
Rated Output: 500 A at 42V, 600 A at 38 V
Generator Output: 0-600 Amp
Auxiliary Power: 3 phase 18,000W continuous, 1 phase: 3,000 W
Single Phase Auxiliary Peak Power: 3000 W
Sound Rating: Idle: 76.3 dB, Weld: 76.1 dB
Applications: Fabrication, Mobile Fabrication & MRO, Process Pipe, Structural Welding
Net Width: 724mm
Net Height: 1168mm (1,359mm including the exhaust)
Net Length: 1,765mm
Net Weight: 916kg ( without fuel )
Warranty: 3 Years Miller’s True Blue Warranty
