Amperage: 20 A – 400 A
Weldable Metals: Stainless Steel, Steel
Rated Carbon Diameter: 3/16 in (4.8 mm)
Current Type: DC
Max Open Circuit Voltage: 85 VDC
Portability: Lift Eye (Standard) | Trailer (Optional)
Cold Weather Starting Aids: Engine Block Heater, Glow Plugs
Engine Brand: Kubota
Engine Compliance: T4F
Engine Idle Speed: 1500 RPM
Engine Weld Speed: 1800 RPM
Fuel Tank Size: 11.5 Gallons
Fuel Type: Diesel
Horsepower: 20.2 hp
Weld Output: CC / CV
Rated Output: 400 A at 24 V, 100% Duty Cycle,350 A at 27 V, 100% Duty Cycle,300 A at 32 V, 100% Duty Cycle
Generator Output: 20-400 Amp 12Kva
Single Phase Auxiliary Continuous Power: 10000 W
Single Phase Auxiliary Peak Power: 12000 W
Sound Rating: Idle: 66 dB, Weld: 71.6 dB
Applications: Fabrication, Mobile Fabrication & MRO, Process Pipe, Structural Welding
Net Width: 26.25 in
Net Height: 32 in
Net Length: 56 in
Net Weight: 950 lbs
Warranty: 3 Years Miller’s True Blue Warranty
Download Manual: https://www.millerwelds.com/files/owners-manuals/O281496S_MIL.pdf
