Description
The Rotabroach Element 100S/3 Magnetic Drill is a high-performance 2000 W machine engineered for precision and heavy-duty metal drilling. Featuring a 100 x 100 mm capacity, 4-speed operation, 25 kg weight, and M30 tapping capability, it provides stability, power, and accuracy for demanding industrial and fabrication applications.
-
Rotabroach’s largest machine (733mm)
-
Suitable for drilling up to 100mm diameter by 100mm depth
-
Forward and reverse functionality for tapping.
-
Supplied as either a swivel base or a non-swivel option.
-
Dual motor protection system to prolong the machine’s life and prevent unwanted wear
-
13mm drill chuck that can be used for twist drills
-
Powerful 2000w motor with a two speed mechanical gearbox
- Can be used to countersink up to 40mm*
-
CutSmart Technology – designed to protect your motor and cutter, prolonging tool life.
-
Quick release interchangeable handle – allowing you to operate the mag drill from either side and improving accessibility.
-
Internal cabling removed the risk of damage and downtime
| Model Number |
Element 100/3 |
|---|---|
| Motor Specification |
230V 2000W |
| No load RPM |
Gear 1: 45-129 RPM Gear 2: 70-208 RPM Gear 3: 150-434 RPM Gear 4: 240-700 RPM |
| Max Hole Cutting Capacity |
ø100 x 100mm Deep – 31.75 with MT Drill |
| Overall Dimension |
Height: 560mm / Width: 230mm with Capstan / Length: 460mm with Guard |
| Machine Weight |
24.8kg |
| Magnetic Adhesion |
20,000N |
| Magnet Size |
228mm x 114mm |
| Safety Features |
Cutsmart™ Technology / Fixed Guard / Magnetic Detection |
